320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ

Ask Lasest Price
Brand Name :	DL
Model Number :	P2
Certification :	CE,ROHS,PSE,UL
Price :	Negotiate
Payment Terms :	T/T, Western Union, MoneyGram
Delivery Time :	5-15days

Add to Cart

Product Details
Company Profile

320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ

3840HZ SMD1515 P2 Indoor Led Module 320mm*160mm Led Display Panel
P2

1. High refresh rate: 3840Hz, which can make clearer and vivider
piture,No chromatic
2. Seamless Assembly:Made through CNC,Assembly accuracy 0.1mm
3. Easy to move and fast installation: Light weight, Die-casting
Aluminum Cabinet,Lighter and Slimmer
4. Fully-front service, very suitable for wall-mounted installation
5. Option for rental events solution

Module Specification:
Dimensions(WxH)320×160mmResolution(WxH)160×80dots
Pixel Pitch(mm)2Pixel Density250000 pixels/m2
Pixel ConfigurationSMD 2121
LED parametersR WL(620-625NM)
IV:(600-800mcd)
G: WL:(520-524nm)
IV:(1400-1800mcd)
B:WL:(470-472nm)
IV :(800-880mcd)

Cabinet Specification:
Dimensions (WxH)640mm x 480mmModule Quantity6
Physical Resolution(WxH)320 x240 dotsPhysical Pixels (Total)76800
Weight/Cabinet8KGMaterialDie-Castiing aluminum

LED Display Parameter:
item
value
Pixel Pith
2mm
Module Size
320mm×160㎜
Module Resolution
160×80 dots
Cabinet Size
640mm×480mm×58mm
Cabinet Resolution
320×240 dots
Resolution
250000 dots/㎡
Brightness
≤800cd/㎡
Refresh Frequency
1920Hz
Grey Level
16bits
Driving Mode
Constant current
Avg Consumpation
260W/㎡
Max. Consumpation
650w/㎡
Input voltage
AC110-240
Viewing Distance
2-60m
viewing Angle
Horizontal 140deg. Vertical 140deg.
Lifetime at 50% brightness
100,000 hours
Operating temperature
-20℃ ～ +55℃
Operating humidity
10％ ～ 90％
Source compatibility (with video processor)
HDMI, HDSDI, SDI, VGA, RJ45, YC



Product Description

1. Lightweight. Convenient in transporting and installing & saving
labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person
without tool.
4. Humanized operating interface with breakdown indicator lights,
easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving
the debugging technology for nice image.

Product Tags:

320mm*160mm Indoor Led Display Panel

3840HZ Indoor Led Display Panel

3840HZ indoor led panel

320mm*160mm Indoor Led Display Panel with High refresh rate 3840HZ
