P2 Die Casting Rental Small Pixel 80*160 Dot Matrix Led Display Video Wall Module 1/20 Scan

DL LED is a professional LED Signs manufacturer for more than 10years history. Our LED Window Display Signs with high brightness, and user-friendly software including PC and APP version which makes you free to update the content everyday. The wireless LED scrolling sign would show the ultra bright text to help you attract your client eyes to increase business. Also our illuminated window signs is with UL certified power supply, which ensure the most durable quality for the LED Board .

1. Lightweight. Convenient in transporting and installing & saving labor cost, suitable for flow shows.

2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person without tool.
4. Humanized operating interface with breakdown indicator lights, easy to maintain.
5. High debugging brightness and no damage to gray scale, achieving the debugging technology for nice image.

Module Specification:

Dimensions(WxH)	320×160mm	Resolution(WxH)	160×80dots
Pixel Pitch(mm)	2	Pixel Density	250000 pixels/m2
Pixel Configuration	SMD 2121
LED parameters	R WL(620-625NM) IV:(600-800mcd)	G: WL:(520-524nm) IV:(1400-1800mcd)	B:WL:(470-472nm) IV :(800-880mcd)

Cabinet Specification:

Dimensions (WxH)	640mm x 480mm	Module Quantity	6
Physical Resolution(WxH)	320 x240 dots	Physical Pixels (Total)	76800
Weight/Cabinet	8KG	Material	Die-Castiing aluminum

LED Display Parameter:

item	value
Pixel Pith	2mm
Module Size	320mm×160㎜
Module Resolution	160×80 dots
Cabinet Size	640mm×480mm×58mm
Cabinet Resolution	320×240 dots
Resolution	250000 dots/㎡
Brightness	≤800cd/㎡
Refresh Frequency	1920Hz
Grey Level	16bits
Driving Mode	Constant current
Avg Consumpation	260W/㎡
Max. Consumpation	650w/㎡
Input voltage	AC110-240
Viewing Distance	2-60m
viewing Angle	Horizontal 140deg. Vertical 140deg.
Lifetime at 50% brightness	100,000 hours
Operating temperature	-20℃ ～ +55℃
Operating humidity	10％ ～ 90％
Source compatibility (with video processor)	HDMI, HDSDI, SDI, VGA, RJ45, YC

1.Technical Support
(a) we provide free technical support, which includes operation training and maintenance training in the factory
(b) we can send our engineers to your country after negotiation
2, Maintenance and Consultation
(a) we provide full maintenance for a lifetime and only charge the raw material cost
(b) we also provide lifetime consultation through Email, SMS, Phone call, etc.
3, Documents and Certificates

(a) we provide all necessary user's manual, software, test report, CAD drawing, etc.
(b) we can also provide all kinds of certificates, such as CE, RoHS etc.

.
