High Quality P8 Outdoor Waterproof Led Advertising Display Board
Product Description:
* Die-casting aluminum, secure and nice in constitution.
* No fans, mute when operation.
* Dustproof and Waterproof, IP65.
* High refresh rate and high gray depth.
* Completely black LED with high contrast.
* Standard cabinet size is 640mm x 640mm.
* Large viewing angle, the panel viewing angle is up to 140, the
vertical angle could reach 140, the image won't be out of shape and
color cast between the rang.
* Exactly connected and easy to install and dismount.
LED Display Parameter
| Pixelpitch(mm) | P8 |
| LED Encapsulation | CREE SMD3535 |
| Density(dot/m2) | 15625/sqm |
| Module size LxH mm | 256*128mm |
| Module Resolution | 32*16dot |
| Viewing Distance | 8-20m |
| viwe angle(H)- (V) | 120°- 120° |
| Brightness (cd/m²) | 7200 |
| average consumption m² | 550w |
| Max consumption m² | 1100w |
| Driving method | -25-65℃ |
| scan mode | 1/8scan |
| MTBF | ﹥100000 |
| Frame frequency | 60Hz |
| input voltage | 110-220V |
| Color temperature | 6500K |
| IP rating | IP65/IP55 |
| Signal input format | Composite, S-Video, VGA, DVI, YPbPr, HDMI, SDI |
1. Lightweight. Convenient in transporting and installing & saving
labor cost, suitable for flow shows.
2. Nice appearance and simple structures.
3. Jointed correctly, being installed & dismounted by one person
without tool.
4. Humanized operating interface with breakdown indicator lights,
easy to maintain.
5. High debugging brightness and no damage to gray scale,achieving
the debugging technology for nice image.
Packing:
FAQ:
Q2: Where is it used for?
A2: Indoor & rental use. Widely used for backdrop of staging event,
rental business, liveshow, concert, etc.
Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar controlling
system.
Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar.
Also support other controlling system, like Linsn, etc.
Q5: How about the size of project?
A5: Please offer the size with "width by height" of project. We wil
offer the suitable solution for your project size. I will
appreciate it if any drawing files about installation offered.
